Key Features
- The six-sided heating system ensures the high-temperature uniformity.
- The second-generation infrared CO2 sensor can automatically compensate based on the temperature and pressure, etc., with high reliability.
- The dry heat sterilization system of 160 ℃ - 180 ℃ can completely sterilize products. All parts in the box do not need to be disassembled, and one-click sterilization operation is convenient.(POG series)
- Air duct UV sterilization, sterilizing while culturing.(POU series)
- The unique dual circulation air duct design has non-natural convection, ensuring high uniformity of temperature, humidity and CO2 concentration within the box.
- Naturally humidifies via water plate, accurately controls humidity, and can increase and remove humidity.
- Zirconia oxygen sensor, precise and durable.
- Dual temperature sensors ensure temperature accuracy and accuracy within the box.
Technical Specification
|
Model |
POG-90A POU-90A |
POG-150A POU-150A |
POG-260A POU-260A |
|
Supply voltage |
AC220V/50HZ |
AC220V/50HZ |
AC220V/50HZ |
|
Input power |
1300W |
1300W |
1300W |
|
Operating ambient temperature |
19℃-25℃ |
19℃-25℃ |
19℃-25℃ |
|
Display screen |
4.3-inch color touch screen |
4.3-inch color touch screen |
4.3-inch color touch screen |
|
Volume of box |
106L |
175L |
300L |
|
Temperature control range |
R.T.+3 ℃ - 55 ℃ |
R.T.+3 ℃ - 55 ℃ |
R.T.+3 ℃ - 55 ℃ |
|
Temperature display accuracy |
±0.1(37℃) |
±0.1(37℃) |
±0.1(37℃) |
|
Temperature resolution |
0.1℃ |
0.1℃ |
0.1℃ |
|
Temperature uniformity |
± 0.3 (37 ℃, r.t.25 ℃) |
± 0.3 (37 ℃, r.t. 25 ℃) |
± 0.3 (37 ℃, r.t. 25 ℃) |
|
Temperature control mode |
PID microcomputer control |
PID microcomputer control |
PID microcomputer control |
|
CO2 range |
0%-20% |
0%-20% |
0%-20% |
|
CO2 control accuracy |
±0.1%(5%，37℃) |
±0.1%(5%，37℃) |
±0.1%(5%，37℃) |
|
CO2 resolution |
0.1% |
0.1% |
0.1% |
|
CO2 sensor |
Infrared CO2 sensor with automatic compensation based on temperature and pressure, etc. |
||
|
CO2 control |
PID microcomputer control |
PID microcomputer control |
PID microcomputer control |
|
O2 sensor |
Zirconia sensor |
Zirconia sensor |
Zirconia sensor |
|
O2 control accuracy |
±0.1% |
±0.1% |
±0.1% |
|
O2 control range |
0.5%-21% |
0.5%-21% |
0.5%-21% |
|
O2 control resolution |
0.1% |
0.1% |
0.1% |
|
O2 control |
PID microcomputer control |
PID microcomputer control |
PID microcomputer control |
| 160℃-180℃ dry heat sterilization | only for model POG-90A POG-150A POG-260A | ||
| UV sterilization | only for model POU-90A POU-150A POU-260A | ||
| Humidity Control |
High temperature resistant silver ion antibacterial humidifying plate for natural humidification, precise humidity control, and air pump dehumidification |
||
|
Inner material |
Antibacterial stainless steel |
Antibacterial stainless steel |
Antibacterial stainless steel |
|
Number of plates |
Standard configured 3 pieces |
Standard configured 3 pieces |
Standard configured 4 pieces |
|
Dimension of inner incubator |
W450×D450×H550mm |
W540×D560×H580mm |
W600×D560×H900mm |
|
External dimensions |
W590×D630×H890mm |
W680×D715×H900mm |
W730×D715×H1220mm |
