Key Features:
- The six-sided heating system ensures the high-temperature uniformity.
- The second-generation infrared CO2 sensor can automatically compensate based on the temperature and pressure, with high reliability.
- Unique dual circulation air duct design, non-natural convection, ensuring high uniformity of temperature, humidity and carbon dioxide concentration within the box.
- Antibacterial stainless steel liner material inhibits the growth of microorganisms on the liner and ensures the cleanliness of the inner incubator.
Technical Specifications:
|
Model |
P-MINI |
|
Supply voltage |
AC110V/50Hz |
|
Power |
Max. 600W |
|
Display screen |
4.3-inch Touch Screen |
|
Volume of box |
25L OR 40L |
|
Temperature control range |
R.T.+3-55 ℃ (at RT25 ℃) |
|
Temperature display accuracy |
±0.1 |
|
Temperature uniformity (measured at R.T. 25 ℃) |
When the set temperature is 37 ℃, the temperature uniformity is ≤ ± 0.3 ℃ |
|
Temperature control mode |
PID microcomputer control |
|
CO2 range |
0-20% |
|
CO2 control accuracy |
±0.1% (5%，37℃) |
|
CO2 resolution |
0.1% |
|
CO2 sensor |
Infrared CO2 sensor |
|
CO2 control |
PID microcomputer control |
|
inner material |
Antibacterial stainless steel |
|
Number of plates |
Standard configured 2 pcs |
|
Test hole |
Optional (inner diameter 38 mm) |
|
Dimension of inner incubator |
W285 × D355 × H265(25L) W305 × D400 × H355(40L) |
|
External dimensions |
W400 × D520 × H446(25L) W410 × D520 × H540(40L) |
|
Heating method |
Six-side heating |
|
Humidification method |
water plate |
|
|
With data recording function, the recording time can be set, 150000 pieces of data can be recorded, and the temperature curves can be displayed to facilitate data analysis; there is a USB interface to export and save the above data; |
|
With overtemperature alarm function and overtemperature automatic heating switching-off function |
