Key Feature:
- The six-sided heating system ensures the high-temperature uniformity.
- Unique dual circulation air duct design and non-natural convection ensure the high uniformity of temperature inside the box.
- A programmable cyclic damp heat test humidifier is adopted to humidify rapidly.
- Provided with over-temperature alarm function, over-temperature automatic shutdown heating function and power failure recovery automatic startup function.
Technical Specification:
|
Model |
chamber HCP-90 |
chamber HCP-150 |
chamber HCP-260 |
|
Supply voltage |
AC110V/50Hz |
AC110V/50Hz |
AC110V/50Hz |
|
Input power |
1300W |
1300W |
1300W |
|
Operating ambient temperature |
19℃-25℃ |
19℃-25℃ |
19℃-25℃ |
|
Display screen |
4.3-inch color touch screen |
4.3-inch color touch screen |
4.3-inch color touch screen |
|
Volume of box |
106L |
175L |
300L |
|
Temperature control range |
R.T.+5 ℃ - 160 ℃ |
R.T.+5 ℃ - 160 ℃ |
R.T.+5 ℃ - 160 ℃ |
|
Temperature display accuracy |
±0.1(37℃) |
±0.1(37℃) |
±0.1(37℃) |
|
Temperature resolution |
0.1℃ |
0.1℃ |
0.1℃ |
|
Temperature uniformity |
± 0.3 (37 ℃, room temperature 25 ℃) |
||
|
Temperature control mode |
PID microcomputer control |
PID microcomputer control |
PID microcomputer control |
|
Humidity control range |
Ambient humidity - 98% RH (without humidity control at the temperature above 70 ℃) |
||
|
Humidity control accuracy |
≤ ± 3% (at 37 ℃) |
≤ ± 3% (at 37 ℃) |
≤ ± 3% (at 37 ℃) |
|
Humidity resolution |
0.1% |
0.1% |
0.10% |
|
Humidity recovery time |
Open the door for 1 minute, and and the humidity will be recovered within the standard requirements within 25 minutes after closing the door |
||
|
Volume of water storage tank |
1L |
1L |
1L |
|
Humidity Control |
A programmable cyclic damp heat test humidifier is equipped |
||
|
Inner material |
Antibacterial stainless steel |
Antibacterial stainless steel |
Antibacterial stainless steel |
|
Number of partition plates |
Standard configured 3pcs |
Standard configured 3pcs |
Standard configured 4pcs |
|
Dimension of inner incubator |
W450×D450×H550mm |
W540×D560×H580mm |
W600×D560×H900mm |
|
External dimensions |
W590×D630×H890mm |
W680×D715×H900mm |
W730×D715×H1220mm |
