Model: P-90A 150A 260A
- Natural humidification
- Dry heat sterilization at 160℃-180℃（adjustable）
Model: P-90B 150B 260B
- Automatic humidity control via humidifier
- Dry heat sterilization at 160℃-180℃（adjustable）
Model: PU-90A 150A 260A
- Natural humidification
- UV sterilization
Model: PU-90B 150B 260B
- Natural humidification
- UV sterilization
- Automatic humidity control via humidifier
Key Features:
- The six-sided heating system ensures the high-temperature uniformity
- Infrared CO2 sensor can automatically compensate based on the temperature and pressure, etc., with high reliability.
- The dry heat sterilization system of 160 ℃ - 180 ℃ can completely sterilize products. All parts in the box do not need to be disassembled, and one-click sterilization operation is convenient.(only model P-90A/B 150A/B 260A/B)
- The UV sterilization of air duct can timely purify the air inside the box, without affecting the culture during sterilization, and the UV lamp is convenient for replacement.(only model PU-90A/B 150A/B 260A/B)
- The unique dual circulation air duct design has non-natural convection, ensuring high uniformity of temperature, humidity and CO2 concentration within the box.
- Naturally humidifies via water plate.(A series)
- A programmable cyclic damp heat test humidifier for humidification.(B series)
Technical Specifications:
|
Model
|
P-90A / B
PU-90A / B
|
P-150A / B
PU-150A / B
|
P-260A / B
PU-260A / B
|
|
Supply voltage
|
AC220V/50Hz
|
AC220V/50Hz
|
AC220V/50Hz
|
|
Input power
|
1300W
|
1300W
|
1300W
|
|
Operating ambient temperature
|
19℃-25℃
|
19℃-25℃
|
19℃-25℃
|
|
Display screen
|
4.3-inch color touch screen |
|
Volume of box
|
106L
|
175L
|
300L
|
|
Temperature control range
|
R.T.+5 ℃ - 55 ℃(@25℃) |
|
Temperature display accuracy
|
±0.1(37℃)
|
±0.1(37℃)
|
±0.1(37℃)
|
|
Temperature resolution
|
0.1℃
|
0.1℃
|
0.1℃
|
|
Temperature uniformity
|
± 0.3 (37 ℃, R.T. 25 ℃)
|
± 0.3 (37 ℃, R.T. 25 ℃)
|
± 0.3 (37 ℃, R.T. 25 ℃)
|
|
Temperature control mode
|
PID microcomputer control |
|
CO2 range
|
0%-20%
|
0%-20%
|
0%-20%
|
|
CO2 control accuracy
|
±0.1%(5%，37℃)
|
±0.1%(5%，37℃)
|
±0.1%(5%，37℃)
|
|
CO2 resolution
|
0.1%
|
0.1%
|
0.1%
|
|
CO2 sensor
|
Infrared CO2 sensor with automatic compensation based on temperature and pressure, etc.
|
|
CO2 control
|
PID microcomputer control |
| Natural humidification |
A series |
A series |
A series |
| Volume of water pan |
1500ml
|
2500ml
|
4150ml |
| Automatic humidity control via humidifier |
B series |
B series |
B series |
|
Humidity control range
|
Ambient humidity: -98%RH
|
|
Humidity control accuracy
|
≤ ± 2% (at 37 ℃)
|
|
Humidity resolution
|
0.1%
|
|
Humidity recovery time
|
Open the door for 1 minute, and and the humidity will be recovered within the standard requirements within 25 minutes after closing the door
|
|
Volume of water storage tank
|
1L
|
1L
|
1L
|
|
Inner material
|
SUS304 Antibacterial stainless steel |
|
Number of inner shelves
|
Standard configured 3nos
|
Standard configured 3nos
|
Standard configured 4nos
|
|
Interior dimensions
|
W450×D450×H550mm
|
W540×D560×H580mm
|
W600×D560×H900mm
|
|
External dimensions
|
W590×D630×H890mm
|
W680×D715×H900mm
|
W730×D715×H1220mm
|
